Mega-Pixel Vari-Focal Lens
f=2.8-8mm (Model: M13VM288IR)
TAMRON
Tamron makes a series of mega-pixel compatible vari-focal lenses that derive the maximum performance from mega-pixel high-resolution cameras. Tamron's mega-pixel compatible Vari-Focal lenses incorporating advanced optical systems ensure high resolution and high contrast performance over the entire image field, from the center to the periphery. Also, these lenses are the most suitable for the image cut-out function of IP cameras.

SPECIFICATIONS
Model No. M13VM288IR
Imager Size 1/3″  (1/2.7″,1/2.8″)
Focal Length 2.8–8mm
Mount CS-Mount
Aperture Range F1.2–Close
Focusing Range 0.3m–∞
Angle of View
(Horizontal
× Vertical)		 1/3″ WIDE 100.1°×72.9°
TELE 35.8°×26.8°
1/4″ WIDE 72.9°×53.9°
TELE 26.8°×20.1°
Operation Focus Manual with Lock
Zoom Manual with Lock
Iris Manual with Lock
Filter Size –
Back Focus(in Air) Wide 8.339–Tele 14.944mm
Wave Size Visible Light–Infrared Light
Weight 61g
Operating Temperature -20℃+60℃
