Mega-Pixel Vari-Focal Lens (DC Auto Iris)
f=2.4-6mm (Model: M13VG246)
TAMRON
Tamron makes a series of mega-pixel compatible vari-focal lenses that derive the maximum performance from mega-pixel high-resolution cameras. Tamron's mega-pixel compatible Vari-Focal lenses incorporating advanced optical systems ensure high resolution and high contrast performance over the entire image field, from the center to the periphery. Also, these lenses are the most suitable for the image cut-out function of IP cameras.

SPECIFICATIONS
Model No. M13VG246
Imager Size 1/3″
Focal Length 2.4–6mm
Mount CS-Mount
Aperture Range F1.2–Close
Focusing Range 0.3m–∞
Angle of View
(Horizontal
× Vertical)		 1/3″ WIDE 111.3°×83.5°
TELE 47.1°×35.4°
1/4″ WIDE 83.5°×62.6°
TELE 35.4°×26.6°
Operation Focus Manual with Lock
Zoom Manual with Lock
Iris Manual with Lock
Filter Size –
Back Focus(in Air) Wide 7.84–Tele 13.72mm
Operating Voltage Open 4.0V/Close 0.7V
Wave Size Visible Light
Weight 75g
Operating Temperature -20℃–+60℃


Wiring Diagram
